RussianSDD Engine Bus Air Conditioner Series
Double-return A/C, suitable for 6-14m buses and long-distance coaches.
-
6-14m
Application vehicle length
-
22000-34000 kcal/h
Cooling capacity
-
R134a
Refrigerant
-
156-233 kg
Weight
Technical Parameters
| Model | SDD-03 | SDD-04 | SDD-05 | SDD-06 | SDD-07 |
| Cooling capacity |
22000kcal/h 26kW 88000BTU/h |
24000kcal/h 28kW 96000BTU/h |
28000kcal/h 33kW 112000BTU/h |
32000kcal/h 37kW 127000BTU/h |
34000kcal/h 40kW 135000BTU/h |
| Maximum energy consumption (A) | 75 | 75 | 80 | 100 | 110 |
| Evaporation air volume (m³/h) | 4000（4pcs） | 4000（4pcs） | 6000（6pcs） | 8000（8pcs） | 8000（8pcs） |
| Condensing air volume (m³/h) | 6000（3pcs） | 6000（3pcs） | 8000（4pcs） | 10000（5pcs） | 12000（6pcs） |
| Compressor displacement (cc) | 400 | 558 | 558 | 647 | 744 |
| Refrigerant | R134a | R134a | R134a | R134a | R134a |
| Weight (kg) | 156 | 156 | 206 | 230 | 233 |
| Dimension (mm) LxWxH | 2500*2000*220 | 2500*2000*220 | 2750*2000*220 | 3000*2000*220 | 3000*2000*220 |
| Application | 6-7m | 8-9m | 10-11m | 12-13m | 13-14m |
Unfold
Features
