YTH06 South American High-end Passenger Vehicle Passenger's Seat

The product is applicable to T-series high-end tourist models, meeting different market demands such as passenger transportation, tourism, commuter travel.

1045mm

Width of the whole seat (mm)
780 (0, -10)mm

Depth of the whole seat
45mm/47mm

Backrest thickness (mm)
466 (-5, 5)mm

Seat cushion width

Get a quote WhatsApp

Technical Parameters

Product Parameter Information
Backrest height	1175(-10,10)mm
Backrest width	470(-5,5)mm
Seat cushion depth	466(-5,5)mm
Seat cushion width	469(-5,5)mm
Backrest thickness	45(0,+5)mm
Backrest initial angle	122°
Seat cushion height	479(-10,10)mm
Backrest adjustment angle	30°
Width of the whole seat (mm)	1045(-10,10)mm
Depth dimension of whole seat	780(-10,10)mm
Product Function Configuration Information
Exterior handrail	Standard configuration
Interior handrail	Optional
Middle handrail	Standard configuration
Seat pocket	Standard configuration
Cup holder	Optional
Coat hook	Optional
USB charging	Standard configuration
Pedal	Optional
Seat belt alarm	Optional
3-point seat belt	Standard configuration
2-point retracting seat belt	Optional
TV	Optional
Tray table	Optional

Unfold

Features

High safety

It has obtained the domestic 3C certificate and meets the strength requirements of EU ECE standard.

Good comfort

The seat surface is bonded with memory sponge, which makes it soft to ride and has good support performance. It conforms to the using habits of South American customers. The overall shape of the seat is full and the wrapping property is strong. The side handrail in the new appearance design not only has a high-grade appearance, but also is more durable.

Environmental protection

The backrest is made of steel frame structure, completely abandoning plywood material to reduce the peculiar smell of formaldehyde and benzene series. The professional and strict selection of environmental-friendly materials and advanced system detection of the whole seat environment chamber make the seat smell fresher.

Functionality

The seat backrest can be adjusted within the angle range of 0-30° to meet the riding space of passengers with different sizes; the new handrail integrates plastic cup holder, which is beautiful and elegant; the backrest integrates USB and coat hook to improve the riding experience of passengers.
